Brazil's Foz do Iguaçu is located in the very southwest corner of the state of Paraná. More importantly, it is one the nation's treasures, boasting popular scenic attractions such as Iguaçu Falls, the Iguaçu National Park, and the city's Bird Park, amongst other things. Sites such as these ensure Foz do Iguaçu remains one of Brazil's top tourist attractions each year. In fact, Foz do Iguaçu's beauty has achieved such international acclaim that travellers from the Americas, Europe, and Asia already comprise a large percentage of the city's annual tourist percentage.

With this level of prosperity, there is a downside as well. Much of Foz do Iguaçu’s beauty is a result of its unique geographic position – a location that places it bordering Brazil, Paraguay, and Argentina, as well as next to its Paraguayan sister city of Ciudad del Este and Argentine Puerto Iguazú. Yet, this unique connection also offers the inevitable opportunity for transnational criminals to smuggle illicit contraband between the countries.

Completed in June, 2012, this project represents VMI’s first Brazilian public project utilising over a hundred Hikvision cameras. Alvaro De Souza, CCTV Manager at VMI, stated: "The overall goal of this project is to protect both Brazil and Foz do Iguaçu’s tourism-friendly city. For example, our waterfall is internationally famous, and we cannot allow crime to create a negative perception. This is very important, so we chose Hikvision’s DS-2DF1-517-B WDR network high speed dome to accomplish these goals."

There were 120 units of the DS-2DF1-517-B placed in strategic locations throughout the city and border regions. Specifically, these cameras were placed on two types of poles – one measuring 7 metres and the other 15 metres, respectively. Mr. Souza noted, “Using heights of 15 metres can pose problems for some cameras, but it is perfect for the DS-2DF1-517-B. Importantly, its vertical range from -5 degrees to 185 degrees allows us to see someone standing directly below, as well as a helicopter flying directly above. Also, the 570 lines in HD, 36x zoom, and 12x digital zoom, give us a great picture of a person or car that is of interest.”

Additionally, urban outdoor environments can cause serious challenges. Obviously, outdoor environments force electronics to handle the stress changing weather brings. As well, there are differing lighting conditions from day to night, or car headlights, which can also interfere with the performance of a camera. To combat issues of this nature, the DS-2DF1-517-B’s IP66 rating ensures the outdoor longevity of the camera; while an IR cut filter provides true day / night functionality and excellent coverage – regardless of time of day. Additionally, 128x wide dynamic range successfully compensates for artificial light, such as car headlights and illuminated store fronts.

Mr. Souza added, "Since this is a project that requires us to view a variety of subjects, from people to cars, we needed a great deal of technical flexibility. With this camera, we can follow a fast-moving car with 540 degrees of horizontal speed and 400 degrees in vertical speed, and can change our camera presets in .5 second. It’s not a problem to track anything we might encounter."

Additional technical features that help the DS-2DF1-517-B succeed are a 1/4" Sony Exview HAD progressive scan CCD, 3D intelligent positioning functionality, 3D digital noise reduction, and a programmable alarm triggering mechanism.

In Brazil, government policy states that all public security projects must use software that accepts a wide range of hardware manufacturers. In effect, if a hardware manufacturer’s products only work with their own specific software, they will not be allowed in Brazil’s public sector. This is no problem for Hikvision camera lines in general, and the DS-2DF1-517-B in particular; as Hikvision’s cameras use open-sourced SDK. Additionally, Hikvision is part of PSIA and ONVIF and integrated with open-source VMS software, as well.

"Hikvision is a leader in both technical and quality aspects. But, it is also a leader in the little things that make a company successful, such as open-sourced SDK. Aspects like this are vital for markets like Brazil, and for this reason, I am really excited about Hikvision’s expansion into future Brazilian public surveillance projects such as Foz do Iguaçu."
